About Solar Photovoltaic (PV) Panels

Solar Photovoltaic (PV) panels use silicon semi-conductor cells to convert sunlight into electricity to be used to generate electricity into your home or workplace. By Installing Solar Photovoltaic (PV) panels you are saving on energy bills and avoiding long term rising fuel prices. Guaranteed 20 year feed-in tariff payments are paid to you for any power your system produces. These payments are index linked so rise with inflation over time.

By using renewable energy such as Solar PV Panels you can start to change your carbon footprint to a green footprint helping fight climate change and save our planet's future environment.



Our Panels

       The very latest in 'near invisible' installations from Redland. The Duoplain
       Tile panel opens up the possibilities of installing systems where planning permission has previously been
       a stumbling block.





LG 360W Mono Neon R A5

LG

LG 360W Mono Neon R A5

Panels - Monocrystallines

  • Rating: 360W
  • Efficiency: 20.8%
  • Width: 1,016mm
  • Height: 1,700mm
  • Price per watt: (67.5p/Wp)

High Efficiency LG NeON® R Module Cells: 6 x 10 with Module efficiency of 20.8%

Key Features

Enhanced Performance Warranty

LG NeON® R has an enhanced performance warranty. After 25 years, LG NeON® R is guaranteed at least 88.4% of initial performance.

Output warranty of Pmax Linear warranty  1) First year : 98%  2) After 1st year : 0.4% annual degradation 3) 25 years : 88.4%

High Power Output

The LG NeON® R has been designed to significantly enhance its output making it efficient even in limited space.

Aesthetic Roof

LG NeON® R has been designed with aesthetics in mind: no electrode on the front that makes new product more aesthetic. LG NeON® R can increase the value of a property with its modern design.

Outstanding Durability

With its newly reinforced frame design, LG NeON® R can endure a front load up to 6000 Pa, and a rear load up to 5400 Pa

Better Performance on a Sunny Day

LG NeON® R now performs better on a sunny days thanks to its improved temperature coefficient.

Near Zero LID

The n-type cells used in LG NeON® R have almost no boron, which may cause the initial performance degradation, leading to less LID.

Improved Product Warranty

As well as the enhanced performance warranty, LG has extended the product warranty of the LG NeON® R from 15 years to 25 years

Data Sheet https://portal.segen.co.uk/reseller/docs/LG02.5072_NeON_R_370_365_360_Siegel_EN_1805_RZ.pdf

LG 390W Mono Neon2 BiFacial

LG

LG 390W Mono Neon2 BiFacialPart No: LG390N2T-A5 Panels - Monocrystalline BiFacial

  • Rating: 390W
  • Efficiency: 18.5%
  • Width: 1,024mm
  • Height: 2,064mm
  • Price per watt: (52.9p/Wp)

The LG NeON® 2 BiFacial is designed to absorb irradiance not only from the front but also the rear of its NeON® cell by using a trans­parent back sheet. The dual face of the cell allows for higher energy generation.

Thanks to a combination of highly efficient bifacial n-type NeON® cells with Cello technology, which replaces traditional 4 or 5 busbars with 12 thin wires, LG NeON® 2 BiFacial modules can achieve up to 30% more energy than standard PV module.

Enhanced Performance Warranty

LG NeON® 2 BiFacial has an enhanced performance warranty. LG NeON® 2 BiFacial is guaranteed at least 86% of initial performance after 25 years.

Bifacial Energy Yield

LG NeON® 2 BiFacial modules use highly efficient bifacial solar cell with Cello technology. Through the Cello technology, LG NeON® 2 BiFacial can achieve up to 30% more energy than monofacial modules (under optimal conditions)

Better Performance on a Sunny Day

LG NeON® 2 BiFacial now performs better on sunny days thanks to its improved temperature coefficient.

More Generation on a Cloudy Day

LG NeON® 2 BiFacial gives good performance even on a cloudy day due to its low energy reduction in weak sunlight.

BOS (Balance Of System) Saving

LG NeON® 2 BiFacial can reduce the total num­ber of strings due to its high module efficiency resulting in a more cost effective and efficient solar power system.

Near Zero LID (Light Induced Degradation)

The n-type cells used in LG NeON® 2 BiFacial have almost no boron, which may cause the initial efficiency to drop, leading to less LID.

Improved Product Warranty

As well as the enhanced performance warranty, LG has extended the product warranty of the LG NeON® 2 BiFacial from 15 years to 25 years.

Data Sheet https://portal.segen.co.uk/reseller/docs/LG02.0222_NeON2_BiFacial_390_395_Siegel_EN_1805_RZ.pdf



Q Cells 325W Mono Q Peak Duo G5 Black Frame

Q-Cells

Q Cells 325W Mono Q Peak Duo G5 Black FramePart No: Q.PEAK-G5-DUO-325 Panels - Monocrystallines

  • Rating: 325W
  • Efficiency: 19.3%
  • Width: 1,000mm
  • Height: 1,685mm
  • Price per watt: (32.0p/Wp)

Q.PEAK DUO-G5 305-330

The new Q.PEAK DUO-G5 is a monocrystalline solar module with power classes up to 330 Wp and an efficiency of 19.9 %. Q.PEAK DUO-G5 solar modules offer higher yields over smaller surface areas. This is made possible by the new generation of Q.ANTUM's world-record-holding cell concept which has now been combined with state-of-the-art circuitry half cells and a six-busbar design.

The Q CELLS Anti LID Technology eliminates light induced degradation (LID), which can greatly reduce system performance, almost completely. Other conventional monocrystalline solar cells will lose much of their initial performance, once exposed to sunlight. With Q.PEAK DUO-G5 this is not the case, thanks to Anti LID Technology.

Data Sheet https://portal.segen.co.uk/reseller/docs/Hanwha_Q_CELLS_Data_sheet_QPEAK_DUO-G5_305-330_2017-10_Rev01_EN.pdf

Q.PEAK-G5-DUO-320 Q Cells 320W Mono Q Peak Duo G5 Black Frame

Panels – Monocrystallines



  • Rating: 320W
  • Efficiency: 19%
  • Width: 1,000mm
  • Height: 1,685mm

The new Q.PEAK DUO-G5 is a monocrystalline solar module with power classes up to 330 Wp and an efficiency of 19.9 %. Q.PEAK DUO-G5 solar modules offer higher yields over smaller surface areas. This is made possible by the new generation of Q.ANTUM’s world-record-holding cell concept which has now been combined with state-of-the-art circuitry half cells and a six-busbar design. The Q CELLS Anti LID Technology eliminates light induced degradation (LID), which can greatly reduce system performance, almost completely. Other conventional monocrystalline solar cells will lose much of their initial performance, once exposed to sunlight. With Q.PEAK DUO-G5 this is not the case, thanks to Anti LID Technology.

JA Solar Smart Module 300W SK Percium Mono AB

JA Solar

Data Sheet

JA Solar Smart Module 300W SK Percium Mono AB

Panels – SolarEdge Smart

  • Rating: 300W
  • Efficiency: 18.3%
  • Width: 991mm
  • Height: 1,650mm



LG 300W Mono X Plus A5

LG

LG 300W Mono X Plus A5
Panels – Monocrystallines
  • Rating: 300W
  • Efficiency: 17.5%
  • Width: 1,016mm
  • Height: 1,686mm
LG MonoX® Plus
The LG MonoX® Plus is an extremely robust P-type module that maintains high performance by using LG’s LiLY Technology

MonoX® Plus with LiLY Technology
LiLY stands for ‘LID-Improvement for Lifetime Yield’. Conventional P-type solar modules suffer from initial performance degradation called LID(Light Induced Degradation). The combination of Boron and Oxygen is widely known as the main cause of LID. LiLY Technology suppresses the Boron-Oxygen association (and consequently the LID effect), by forming a Boron-Hydrogen pair in the cell manufacturing process

MonoX® Plus – Extreme Physical Durability
The LG MonoX® Plus’s stress endurance is rated to handle up to 6000 Pa on the front side and up to 5400 Pa on the rear side.

Improved Product Warranty
As well as the enhanced performance warranty, LG has extended the product warranty of the LG MonoX® Plus from 15 years to 25 years


Data Sheet LG02.4581_MonoXPlus_Siegel_EN_1805_RZ

Viridian Clearline 300W Mono All Black BIPV

Viridian

Viridian Clearline 300W Mono All Black BIPV
Panels – Monocrystallines
  • Rating: 300W
  • Efficiency: 18.4%
  • Width: 992mm
  • Height: 1,640mm
Roof Integrated solar PV – CLEARLINE Fusion Why Choose Fusion?
  • Economical – price comparable with above-roof installation
  • Rapid – push-fit connections create weather-tight and secure fixing
  • Compact – industry leading panel spacing packs in more power
  • Sleek – invisible clamps for uncluttered aesthetic
  • Simple – no need for roof modifications
  • Robust – wind resistance is more than four times higher than competitor products
  • Universal – works with slate and tile

Clearline fusion PV16 solar PV panels for roof integration are available in a range of power output and styles. Monocrystalline-blackMonocrystalline silicon solar cells are cut from a block of silicon that has been grown as a single crystal. This produces deep black cells with a very high degree of colour uniformity both across the panel and between different panels. We couple these cells with a black backing sheet and a black frame for the last word in high specification aesthetics. Available as a 270Wp panel and 300Wp panel.

Data Sheet Clearline-fusion-PV16-Data-Sheet.



Reliably High Yields
  • High efficiency solar cells together with high transmission textured glass deliver module efficiency of over 15%; leading to minimised installation costs and maximised system output
  • High output due to excellent performance in weak light conditions
  • High specific yields due to positive power sorting
  • Product quality is assured through the use of branded components
Quality Assurance
  • Durability assured in even the harshest of environments with amonia corrosion, salt mist corrosion and fire test certifications.
  • Certified to withstand increased snow and wind loads of up to 5400 Pa.
  • Manufacturing facility certified by ISO 9001, ISO 14001 and OHSAS 18001
  • Internal quality controls with standards higher than both IEC and UL
Warranties
  • 10 year product warranty
  • 25 year performance warranty
  • Free module recycling through PV Cycle Association membership
